Working with Multiple Data Targets 🔗

Albumentations pipelines can apply augmentations consistently across various types of related data, called targets. Beyond just augmenting the input image, you can simultaneously augment corresponding masks, bounding boxes, keypoints, and volumetric data, ensuring spatial transformations are synchronized.

Quick Reference 🔗

Key Concepts:

image or images: Required - primary input data
Spatial transforms: Affect all targets (image, mask, bboxes, keypoints, volumes)
Pixel transforms: Only affect image-like targets (image, images, volumes)
Synchronized augmentation: All targets receive identical spatial transformations
Format configuration: bbox_params and keypoint_params required for respective targets

Common Target Combinations:

Classification: image
Segmentation: image + mask
Object Detection: image + bboxes + bbox_params
Keypoint Detection: image + keypoints + keypoint_params
3D Data Processing: volume + mask3d

Core Requirements 🔗

Mandatory Input 🔗

You must provide either an image or images keyword argument. Other targets like mask, bboxes, etc., are optional and depend on your specific task. All data is passed as keyword arguments to the pipeline call.

Data Type Requirements 🔗

All data passed to Albumentations must be NumPy arrays:

Image-like data (image, images, volume, volumes): Must be uint8 or float32 NumPy arrays
Masks: Can be any integer type NumPy array
Bounding boxes: Must be NumPy arrays, typically float32 with shape (num_boxes, 4)
Keypoints: Must be NumPy arrays, typically float32 with shape (num_keypoints, 2+)
Labels: Must be NumPy arrays (can be string or numeric dtype)

Note: Lists are no longer supported for any data type - all inputs must be NumPy arrays.

Grayscale Image Handling 🔗

Albumentations' Compose automatically handles grayscale images for convenience:

Important Context:

All individual transforms require grayscale images to have an explicit channel dimension (H, W, 1)
Compose provides the convenience layer by automatically handling both formats
This eliminates the need for boilerplate code to check and add channel dimensions

Automatic Channel Dimension Management:

Input flexibility: You can pass grayscale images with or without an explicit channel dimension to Compose
Internal preprocessing: Compose automatically adds a channel dimension if missing:
- (H, W) → (H, W, 1)
- (N, H, W) → (N, H, W, 1) for multiple images
- (D, H, W) → (D, H, W, 1) for volumes
Consistent processing: All transforms then operate on consistent dimensions:
- Single images: ndim=3
- Multiple images/single volumes: ndim=4
- Multiple volumes: ndim=5
Automatic cleanup: If a channel dimension was added, Compose removes it in post-processing, returning the original format

Why This Matters:

import albumentations as A
import numpy as np

# Using Compose - handles both formats automatically
transform = A.Compose([A.HorizontalFlip(p=1.0)])

grayscale_2d = np.random.randint(0, 256, (100, 100), dtype=np.uint8)      # (H, W)
grayscale_3d = np.random.randint(0, 256, (100, 100, 1), dtype=np.uint8)  # (H, W, 1)

# Both work with Compose - no boilerplate needed
result_2d = transform(image=grayscale_2d)  # Compose handles conversion
result_3d = transform(image=grayscale_3d)  # Already in correct format

# Direct transform usage - REQUIRES channel dimension
flip = A.HorizontalFlip(p=1.0)

# This will fail - transforms expect (H, W, 1)
# flipped_2d = flip(image=grayscale_2d)  # ❌ Will not work

# Must add channel dimension for direct usage
grayscale_with_channel = grayscale_2d[..., np.newaxis]  # (H, W) -> (H, W, 1)
flipped = flip(image=grayscale_with_channel)  # ✅ Works correctly

This design eliminates the boilerplate of checking and adding channel dimensions in every transform, while maintaining consistency across the library.

2D Targets 🔗

Single Image Data 🔗

`image`: Primary Input Image 🔗

Description: The main input image for augmentation.

Format: NumPy array with shape:

(height, width, channels) for color images (e.g., RGB)
(height, width) for grayscale images

Example:

import numpy as np
import albumentations as A

# Color image
image = np.random.randint(0, 256, (224, 224, 3), dtype=np.uint8)

# Grayscale image
image_gray = np.random.randint(0, 256, (224, 224), dtype=np.uint8)

transform = A.Compose([A.HorizontalFlip(p=0.5)])
result = transform(image=image)

`mask`: Segmentation Mask 🔗

Description: A segmentation mask corresponding to the input image.

Format: NumPy array with same height and width as the input image:

(height, width) for single-class or multiclass masks
(height, width, num_classes) for multi-channel masks

Behavior:

Spatial transforms: Applied identically to image and mask
Pixel transforms: Do not affect masks

Example:

import albumentations as A
import numpy as np

image = np.random.randint(0, 256, (100, 100, 3), dtype=np.uint8)
mask = np.random.randint(0, 5, (100, 100), dtype=np.uint8)  # 5 classes

transform = A.Compose([
    A.HorizontalFlip(p=1.0),           # Affects both image and mask
    A.RandomBrightnessContrast(p=1.0), # Affects only image
])

result = transform(image=image, mask=mask)
transformed_image = result['image']
transformed_mask = result['mask']  # Flipped but not brightness-adjusted

Multiple Image Data 🔗

`images`: Batch of Images 🔗

Description: Multiple images that receive identical augmentation parameters. Essential for video frames, stereo pairs, or multi-channel data requiring synchronized transformations.

Format: NumPy array with shape:

(num_images, height, width, channels) for color images
(num_images, height, width) for grayscale images

Key Feature: All images receive the exact same sequence and parameters of augmentations.

`masks`: Multiple Masks 🔗

Description: Multiple segmentation masks for instance segmentation or multi-object scenarios.

Format: (num_masks, height, width) - each slice [i, :, :] represents one mask.

Use Case: Instance segmentation where each mask represents a different object instance.

Coordinate-Based Targets 🔗

`bboxes`: Bounding Boxes 🔗

Description: Object bounding boxes with configurable coordinate formats.

Requirements:

Must specify bbox_params in A.Compose
Coordinates and labels handled separately

Supported Formats: pascal_voc, albumentations, coco, yolo

Example:

import albumentations as A
import numpy as np

image = np.random.randint(0, 256, (100, 100, 3), dtype=np.uint8)
bboxes = np.array([[10, 10, 50, 50], [60, 60, 90, 90]])  # [x_min, y_min, x_max, y_max]
class_labels = [1, 2]

transform = A.Compose([
    A.HorizontalFlip(p=1.0),
    A.RandomBrightnessContrast(p=0.5),
], bbox_params=A.BboxParams(
    format='pascal_voc',
    label_fields=['class_labels']
))

result = transform(image=image, bboxes=bboxes, class_labels=class_labels)

`keypoints`: Keypoints/Landmarks 🔗

Description: Points of interest with configurable formats and coordinate systems.

Requirements:

Must specify keypoint_params in A.Compose
Support for 2D and 3D coordinates

Common Formats: [x, y], [x, y, angle, scale], [x, y, z]

3D Note: For XYZ keypoints, 2D transforms only modify x, y coordinates; z remains unchanged.

3D Targets (Volumetric Data) 🔗

Single Volume Data 🔗

`volume`: 3D Data Volumes 🔗

Description: 3D data volumes for various applications including medical imaging (CT, MRI), scientific simulations, geospatial data, computer graphics, and other volumetric datasets.

Format:

(depth, height, width, channels) (DHWC)
(depth, height, width) (DHW)

Transform Behavior:

2D transforms: Applied slice-wise with identical parameters across all slices
3D transforms: Applied to the entire volume
Pixel transforms: Applied slice-wise

`mask3d`: 3D Segmentation Mask 🔗

Description: 3D segmentation mask corresponding to a volume, used for labeling regions in 3D space.

Format: (depth, height, width)

Multiple Volume Data 🔗

`volumes`: Batch of 3D Volumes 🔗

Format: (num_volumes, depth, height, width, channels) or (num_volumes, depth, height, width)

`masks3d`: Multiple 3D Masks 🔗

Format: (num_masks, depth, height, width)

Target Compatibility Matrix 🔗

This simplified matrix shows the general compatibility between transform categories and different targets. Note that individual transforms within each category may have specific limitations.

Transform Category	Description	image	mask	bboxes	keypoints	volume	mask3d
Pixel-level	Modify pixel values only (color, brightness, noise, blur)	✅	❌	❌	❌	✅	❌
Spatial-level	Modify geometry (flip, rotate, crop, resize)	✅	✅	✅	✅	✅	✅
3D-specific	Designed for volumetric data	❌	❌	❌	Sometimes	✅	✅

Key Points:

Pixel-level transforms: Only affect pixel values in images/volumes, leaving spatial information unchanged
Spatial-level transforms: Apply geometric changes consistently across all supported targets
3D transforms: Specifically designed for volumetric data (medical imaging, etc.)

⚠️ Important: This is a simplified overview. Individual transforms may have specific requirements or limitations. For a complete, up-to-date reference of which transforms support which targets, see the Supported Targets by Transform Reference.

Practical Examples 🔗

Semantic Segmentation 🔗

import albumentations as A
import numpy as np

# Prepare data
image = np.random.randint(0, 256, (256, 256, 3), dtype=np.uint8)
mask = np.random.randint(0, 21, (256, 256), dtype=np.uint8)  # 21 classes

# Create pipeline
transform = A.Compose([
    A.RandomCrop(width=224, height=224),
    A.HorizontalFlip(p=0.5),
    A.RandomBrightnessContrast(p=0.2),
    A.Normalize(),
])

# Apply augmentations
result = transform(image=image, mask=mask)

Object Detection 🔗

import albumentations as A
import numpy as np

# Prepare data
image = np.random.randint(0, 256, (416, 416, 3), dtype=np.uint8)
bboxes = np.array([[50, 50, 150, 150], [200, 200, 350, 350]])
labels = ['person', 'car']

# Create pipeline with bbox parameters
transform = A.Compose([
    A.RandomSizedBBoxSafeCrop(width=320, height=320),
    A.HorizontalFlip(p=0.5),
    A.RandomBrightnessContrast(p=0.3),
], bbox_params=A.BboxParams(
    format='pascal_voc',
    label_fields=['labels'],
    min_area=1024,
    min_visibility=0.1
))

# Apply augmentations
result = transform(image=image, bboxes=bboxes, labels=labels)

Multi-Target Pipeline 🔗

import albumentations as A
import numpy as np

# Prepare all data types
image = np.random.randint(0, 256, (300, 300, 3), dtype=np.uint8)
mask = np.random.randint(0, 2, (300, 300), dtype=np.uint8)
bboxes = np.array([[25, 25, 100, 100], [150, 150, 250, 250]])
keypoints = np.array([[50, 50], [200, 200]])
class_labels = [1, 2]
keypoint_labels = ['nose', 'eye']

# Create comprehensive pipeline
transform = A.Compose([
    A.RandomCrop(width=256, height=256),
    A.HorizontalFlip(p=0.5),
    A.Rotate(limit=15, p=0.5),
    A.RandomBrightnessContrast(p=0.3),
],
bbox_params=A.BboxParams(format='pascal_voc', label_fields=['class_labels']),
keypoint_params=A.KeypointParams(format='xy', label_fields=['keypoint_labels'])
)

# Apply to all targets
result = transform(
    image=image,
    mask=mask,
    bboxes=bboxes,
    keypoints=keypoints,
    class_labels=class_labels,
    keypoint_labels=keypoint_labels
)

Best Practices 🔗

Data Consistency 🔗

Shape Matching: Ensure all spatial targets have matching dimensions
Data Types: Use uint8 for images, appropriate types for other targets
Coordinate Systems: Verify bbox/keypoint formats match your data
Array Format: All targets must be NumPy arrays - lists are no longer supported for bboxes, keypoints, or labels

Performance Optimization 🔗

Batch Processing: Use images/masks for multiple related items
Target Selection: Only include targets you actually need
Memory Management: Consider data types and array sizes

Common Pitfalls 🔗

Missing Parameters: Always provide bbox_params/keypoint_params when using bboxes/keypoints
Format Mismatches: Ensure coordinate formats match your data
Shape Inconsistencies: All targets must have compatible spatial dimensions

Where to Go Next? 🔗

Now that you understand how Albumentations handles different data targets, you can:

Task-Specific Guides:

Semantic Segmentation - Working with image and mask
Object Detection - Using image, bboxes, and bbox_params
Keypoint Detection - Handling image, keypoints, and keypoint_params
Volumetric Data - Working with volume, mask3d, and 3D transforms

Advanced Topics:

Additional Targets - Define custom data types beyond standard targets
Pipelines - Understand how A.Compose orchestrates transforms across targets
Supported Targets by Transform - Complete reference of transform-target compatibility

Interactive Learning:

Explore Transforms - Visualize how different transforms affect various targets

Working with Multiple Data Targets 🔗

Quick Reference 🔗

Core Requirements 🔗

Mandatory Input 🔗

Data Type Requirements 🔗

Grayscale Image Handling 🔗

2D Targets 🔗

Single Image Data 🔗

image: Primary Input Image 🔗

mask: Segmentation Mask 🔗

Multiple Image Data 🔗

images: Batch of Images 🔗

masks: Multiple Masks 🔗

Coordinate-Based Targets 🔗

bboxes: Bounding Boxes 🔗

keypoints: Keypoints/Landmarks 🔗

3D Targets (Volumetric Data) 🔗

Single Volume Data 🔗

volume: 3D Data Volumes 🔗

mask3d: 3D Segmentation Mask 🔗

Multiple Volume Data 🔗

volumes: Batch of 3D Volumes 🔗

masks3d: Multiple 3D Masks 🔗

Target Compatibility Matrix 🔗

Practical Examples 🔗

Semantic Segmentation 🔗

Object Detection 🔗

Multi-Target Pipeline 🔗

Best Practices 🔗

Data Consistency 🔗

Performance Optimization 🔗

Common Pitfalls 🔗

Where to Go Next? 🔗

`image`: Primary Input Image 🔗

`mask`: Segmentation Mask 🔗

`images`: Batch of Images 🔗

`masks`: Multiple Masks 🔗

`bboxes`: Bounding Boxes 🔗

`keypoints`: Keypoints/Landmarks 🔗

`volume`: 3D Data Volumes 🔗

`mask3d`: 3D Segmentation Mask 🔗

`volumes`: Batch of 3D Volumes 🔗

`masks3d`: Multiple 3D Masks 🔗
