PyTorch and Albumentations for image classification 🔗

This example shows how to use Albumentations for image classification. We will use the Cats vs. Dogs dataset. The task will be to detect whether an image contains a cat or a dog.

Import the required libraries 🔗

import copy
import os
import random
import shutil
from collections import defaultdict
from urllib.request import urlretrieve

import albumentations as A
import cv2
import matplotlib.pyplot as plt
import torch
import torch.optim
from albumentations.pytorch import ToTensorV2
from torch import nn
from torch.backends import cudnn
from torch.utils.data import DataLoader, Dataset
from torchvision import models
from tqdm import tqdm

cudnn.benchmark = True

Define functions to download an archived dataset and unpack it 🔗

class TqdmUpTo(tqdm):
    def update_to(self, b=1, bsize=1, tsize=None):
        if tsize is not None:
            self.total = tsize
        self.update(b * bsize - self.n)


def download_url(url, filepath):
    directory = os.path.dirname(os.path.abspath(filepath))
    os.makedirs(directory, exist_ok=True)
    if os.path.exists(filepath):
        print("Filepath already exists. Skipping download.")
        return

    with TqdmUpTo(unit="B", unit_scale=True, unit_divisor=1024, miniters=1, desc=os.path.basename(filepath)) as t:
        urlretrieve(url, filename=filepath, reporthook=t.update_to, data=None)
        t.total = t.n


def extract_archive(filepath):
    extract_dir = os.path.dirname(os.path.abspath(filepath))
    shutil.unpack_archive(filepath, extract_dir)

Set the root directory for the downloaded dataset 🔗

dataset_directory = os.path.join(os.environ["HOME"], "datasets/cats-vs-dogs")

Download and extract the `Cats vs. Dogs` dataset 🔗

filepath = os.path.join(dataset_directory, "kagglecatsanddogs_3367a.zip")
download_url(
    url="https://download.microsoft.com/download/3/E/1/3E1C3F21-ECDB-4869-8368-6DEBA77B919F/kagglecatsanddogs_3367a.zip",
    filepath=filepath,
)
extract_archive(filepath)

Filepath already exists. Skipping download.

Split files from the dataset into the train and validation sets 🔗

Some files in the dataset are broken, so we will use only those image files that OpenCV could load correctly. We will use 20000 images for training, 4936 images for validation, and 10 images for testing.

root_directory = os.path.join(dataset_directory, "PetImages")

cat_directory = os.path.join(root_directory, "Cat")
dog_directory = os.path.join(root_directory, "Dog")

cat_images_filepaths = sorted([os.path.join(cat_directory, f) for f in os.listdir(cat_directory)])
dog_images_filepaths = sorted([os.path.join(dog_directory, f) for f in os.listdir(dog_directory)])
images_filepaths = [*cat_images_filepaths, *dog_images_filepaths]
correct_images_filepaths = [i for i in images_filepaths if cv2.imread(i) is not None]

random.seed(42)
random.shuffle(correct_images_filepaths)
train_images_filepaths = correct_images_filepaths[:20000]
val_images_filepaths = correct_images_filepaths[20000:-10]
test_images_filepaths = correct_images_filepaths[-10:]
print(len(train_images_filepaths), len(val_images_filepaths), len(test_images_filepaths))

20000 4936 10

Define a function to visualize images and their labels 🔗

Let's define a function that will take a list of images' file paths and their labels and visualize them in a grid. Correct labels are colored green, and incorrectly predicted labels are colored red.

def display_image_grid(images_filepaths, predicted_labels=(), cols=5):
    rows = len(images_filepaths) // cols
    _, ax = plt.subplots(nrows=rows, ncols=cols, figsize=(12, 6))
    for i, image_filepath in enumerate(images_filepaths):
        image = cv2.imread(image_filepath, cv2.IMREAD_COLOR_RGB)

        true_label = os.path.normpath(image_filepath).split(os.sep)[-2]
        predicted_label = predicted_labels[i] if predicted_labels else true_label
        color = "green" if true_label == predicted_label else "red"
        ax.ravel()[i].imshow(image)
        ax.ravel()[i].set_title(predicted_label, color=color)
        ax.ravel()[i].set_axis_off()
    plt.tight_layout()
    plt.show()

display_image_grid(test_images_filepaths)

png

Define a PyTorch dataset class 🔗

Next, we define a PyTorch dataset. If you are new to PyTorch datasets, please refer to this tutorial - https://pytorch.org/tutorials/beginner/data_loading_tutorial.html.

Out task is binary classification - a model needs to predict whether an image contains a cat or a dog. Our labels will mark the probability that an image contains a cat. So the correct label for an image with a cat will be 1.0, and the correct label for an image with a dog will be 0.0.

__init__ will receive an optional transform argument. It is a transformation function of the Albumentations augmentation pipeline. Then in __getitem__, the Dataset class will use that function to augment an image and return it along with the correct label.

class CatsVsDogsDataset(Dataset):
    def __init__(self, images_filepaths, transform=None):
        self.images_filepaths = images_filepaths
        self.transform = transform

    def __len__(self):
        return len(self.images_filepaths)

    def __getitem__(self, idx):
        image_filepath = self.images_filepaths[idx]
        image = cv2.imread(image_filepath, cv2.IMREAD_COLOR_RGB)

        label = 1.0 if os.path.normpath(image_filepath).split(os.sep)[-2] == "Cat" else 0.0

        if self.transform is not None:
            image = self.transform(image=image)["image"]
        return image, label

Use Albumentations to define transformation functions for the train and validation datasets 🔗

We use Albumentations to define augmentation pipelines for training and validation datasets. In both pipelines, we first resize an input image, so its smallest size is 160px, then we take a 128px by 128px crop. For the training dataset, we also apply more augmentations to that crop. Next, we will normalize an image. We first divide all pixel values of an image by 255, so each pixel's value will lie in a range [0.0, 1.0]. Then we will subtract mean pixel values and divide values by the standard deviation. mean and std in augmentation pipelines are taken from the ImageNet dataset. Still, they transfer reasonably well to the Cats vs. Dogs dataset. After that, we will apply ToTensorV2 that converts a NumPy array to a PyTorch tensor, which will serve as an input to a neural network.

Note that in the validation pipeline we will use A.CenterCrop instead of A.RandomCrop because we want out validation results to be deterministic (so that they will not depend upon a random location of a crop).

train_transform = A.Compose(
    [
        A.SmallestMaxSize(max_size=160),
        A.ShiftScaleRotate(shift_limit=0.05, scale_limit=0.05, rotate_limit=15, p=0.5),
        A.RandomCrop(height=128, width=128),
        A.RGBShift(r_shift_limit=15, g_shift_limit=15, b_shift_limit=15, p=0.5),
        A.RandomBrightnessContrast(p=0.5),
        A.Normalize(mean=(0.485, 0.456, 0.406), std=(0.229, 0.224, 0.225)),
        ToTensorV2(),
    ],
)
train_dataset = CatsVsDogsDataset(images_filepaths=train_images_filepaths, transform=train_transform)

val_transform = A.Compose(
    [
        A.SmallestMaxSize(max_size=160),
        A.CenterCrop(height=128, width=128),
        A.Normalize(mean=(0.485, 0.456, 0.406), std=(0.229, 0.224, 0.225)),
        ToTensorV2(),
    ],
)
val_dataset = CatsVsDogsDataset(images_filepaths=val_images_filepaths, transform=val_transform)

Also let's define a function that takes a dataset and visualizes different augmentations applied to the same image.

def visualize_augmentations(dataset, idx=0, samples=10, cols=5):
    dataset = copy.deepcopy(dataset)
    dataset.transform = A.Compose([t for t in dataset.transform if not isinstance(t, (A.Normalize, ToTensorV2))])
    rows = samples // cols
    _, ax = plt.subplots(nrows=rows, ncols=cols, figsize=(12, 6))
    for i in range(samples):
        image, _ = dataset[idx]
        ax.ravel()[i].imshow(image)
        ax.ravel()[i].set_axis_off()
    plt.tight_layout()
    plt.show()

visualize_augmentations(train_dataset)

png

Define helpers for training 🔗

We define a few helpers for our training pipeline. calculate_accuracy takes model predictions and true labels and will return accuracy for those predictions. MetricMonitor helps to track metrics such as accuracy or loss during training and validation

def calculate_accuracy(output, target):
    output = torch.sigmoid(output) >= 0.5
    target = target == 1.0
    return torch.true_divide((target == output).sum(dim=0), output.size(0)).item()

class MetricMonitor:
    def __init__(self, float_precision=3):
        self.float_precision = float_precision
        self.reset()

    def reset(self):
        self.metrics = defaultdict(lambda: &#123;"val": 0, "count": 0, "avg": 0&#125;)

    def update(self, metric_name, val):
        metric = self.metrics[metric_name]

        metric["val"] += val
        metric["count"] += 1
        metric["avg"] = metric["val"] / metric["count"]

    def __str__(self):
        return " | ".join(
            [
                "&#123;metric_name&#125;: &#123;avg:.&#123;float_precision&#125;f&#125;".format(
                    metric_name=metric_name,
                    avg=metric["avg"],
                    float_precision=self.float_precision,
                )
                for (metric_name, metric) in self.metrics.items()
            ],
        )

Define training parameters 🔗

Here we define a few training parameters such as model architecture, learning rate, batch size, epochs, etc

params = &#123;
    "model": "resnet50",
    "device": "cuda",
    "lr": 0.001,
    "batch_size": 64,
    "num_workers": 4,
    "epochs": 10,
&#125;

Create all required objects and functions for training and validation 🔗

model = getattr(models, params["model"])(pretrained=False, num_classes=1)
model = model.to(params["device"])
criterion = nn.BCEWithLogitsLoss().to(params["device"])
optimizer = torch.optim.Adam(model.parameters(), lr=params["lr"])

train_loader = DataLoader(
    train_dataset,
    batch_size=params["batch_size"],
    shuffle=True,
    num_workers=params["num_workers"],
    pin_memory=True,
)
val_loader = DataLoader(
    val_dataset,
    batch_size=params["batch_size"],
    shuffle=False,
    num_workers=params["num_workers"],
    pin_memory=True,
)

def train(train_loader, model, criterion, optimizer, epoch, params):
    metric_monitor = MetricMonitor()
    model.train()
    stream = tqdm(train_loader)
    for _, (images, target) in enumerate(stream, start=1):
        images = images.to(params["device"], non_blocking=True)
        target = target.to(params["device"], non_blocking=True).float().view(-1, 1)
        output = model(images)
        loss = criterion(output, target)
        accuracy = calculate_accuracy(output, target)
        metric_monitor.update("Loss", loss.item())
        metric_monitor.update("Accuracy", accuracy)
        optimizer.zero_grad()
        loss.backward()
        optimizer.step()
        stream.set_description(
            f"Epoch: &#123;epoch&#125;. Train.      &#123;metric_monitor&#125;",
        )

def validate(val_loader, model, criterion, epoch, params):
    metric_monitor = MetricMonitor()
    model.eval()
    stream = tqdm(val_loader)
    with torch.inference_mode():
        for _, (images, target) in enumerate(stream, start=1):
            images = images.to(params["device"], non_blocking=True)
            target = target.to(params["device"], non_blocking=True).float().view(-1, 1)
            output = model(images)
            loss = criterion(output, target)
            accuracy = calculate_accuracy(output, target)

            metric_monitor.update("Loss", loss.item())
            metric_monitor.update("Accuracy", accuracy)
            stream.set_description(
                f"Epoch: &#123;epoch&#125;. Validation. &#123;metric_monitor&#125;",
            )

Train a model 🔗

for epoch in range(1, params["epochs"] + 1):
    train(train_loader, model, criterion, optimizer, epoch, params)
    validate(val_loader, model, criterion, epoch, params)

Predict labels for images and visualize those predictions 🔗

Now we have a trained model, so let's try to predict labels for some images and see whether those predictions are correct. First we make the CatsVsDogsInferenceDataset PyTorch dataset. Its code is similar to the training and validation datasets, but the inference dataset returns only an image and not an associated label (because in the real world we usually don't have access to the true labels and want to infer them using our trained model).

class CatsVsDogsInferenceDataset(Dataset):
    def __init__(self, images_filepaths, transform=None):
        self.images_filepaths = images_filepaths
        self.transform = transform

    def __len__(self):
        return len(self.images_filepaths)

    def __getitem__(self, idx):
        image_filepath = self.images_filepaths[idx]
        image = cv2.imread(image_filepath)
        image = cv2.cvtColor(image, cv2.COLOR_BGR2RGB)
        if self.transform is not None:
            image = self.transform(image=image)["image"]
        return image


test_transform = A.Compose(
    [
        A.SmallestMaxSize(max_size=160),
        A.CenterCrop(height=128, width=128),
        A.Normalize(mean=(0.485, 0.456, 0.406), std=(0.229, 0.224, 0.225)),
        ToTensorV2(),
    ],
)
test_dataset = CatsVsDogsInferenceDataset(images_filepaths=test_images_filepaths, transform=test_transform)
test_loader = DataLoader(
    test_dataset,
    batch_size=params["batch_size"],
    shuffle=False,
    num_workers=params["num_workers"],
    pin_memory=True,
)

model = model.eval()
predicted_labels = []
with torch.no_grad():
    for images in test_loader:
        images = images.to(params["device"], non_blocking=True)
        output = model(images)
        predictions = (torch.sigmoid(output) >= 0.5)[:, 0].cpu().numpy()
        predicted_labels += ["Cat" if is_cat else "Dog" for is_cat in predictions]

display_image_grid(test_images_filepaths, predicted_labels)

png

As we see our model predicted correct labels for 7 out of 10 images. If you train the model for more epochs, you will obtain better results.
